Postby barjammar » April 1st, 2015, 1:14 am

I have obtained useful images of cassette data input as shown in these images on the web.
http://bajama.mine.nu/~barry/hardware/A ... index.html
If you see a closeout sale at Radio Shack, grab one of these desktop digital recorders.
Barry
Screenshot 2015-04-01 14.09.04.jpg
Last edited by barjammar on April 7th, 2015, 10:37 am, edited 1 time in total.
barjammar

Posts: 2
Joined: April 21st, 2014, 4:13 am

Re: Debug audio input with Oscilloscope

Postby gio74 » April 3rd, 2015, 1:09 pm

wouldn't be easier to take the measure at the mini jack out?
gio74

Posts: 54
Joined: January 30th, 2015, 2:43 pm

Re: Debug audio input altairclone with Oscilloscope

Postby barjammar » April 7th, 2015, 5:58 pm

You are correct but I had it open anyway. Why don't you post a block diagram of the IO with pin outs and test points?
Thanks
barjammar

Posts: 2
Joined: April 21st, 2014, 4:13 am

Re: Debug audio input altairclone with Oscilloscope

Postby toml_12953 » April 9th, 2015, 8:55 am

Thanks for the tip about the digital recorder! I'm using one now and it is more reliable than using analog tapes. Not bad for $4.95 at Radio Shack!
toml_12953

Posts: 229
Joined: June 7th, 2013, 12:54 pm
